POF Heat Shrink Film Outer Packaging Transparent Plastic Folded Transparent Seal POF Heat Shrink Film
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | BM |
| Certification: | ISO |
| Model Number: | BMPE |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3tons |
|---|---|
| Price: | 1.1-2.2usd/kg |
| Packaging Details: | in Rolls with Pallets |
| Delivery Time: | 7-15 working days |
| Payment Terms: | T/T |
| Supply Ability: | 100tons/monthly |
|
Detail Information |
|||
| Product Name: | POF Heat Shrink Film | Material: | POF |
|---|---|---|---|
| Transparency: | Transparent | Width: | 20-90cm |
| Thickness: | 0.015mm | Packaging: | Pallet Or Carton |
| Hs: | 90183900 | Texture: | Soft |
| Highlight: | Transparent POF Heat Shrink Film,Outer Packaging POF Heat Shrink Film,Folded POF Heat Shrink Film |
||
Product Description
POF heat shrink film outer packaging transparent plastic film, folded transparent seal POF heat shrink film
1. POF film is good flexibility and easy to use.
2. The shrinkage rate is large, shrinkage rate can reach 75%.
3. Good welding performance, high strength, suitable for manual, semi-automatic and high-speed automatic packaging.
4. Good cold resistance, suitable for storing and transporting packaged objects in cold environments.
5. Environmentally friendly and non-toxic, can be packaged food.
6. Moisture and dustproof.
7. The packaging cost is low.
Application
Specification
| Test Item | Unit | ASTM Test | Typical Values | |||||
| Thickness | 12.5um | 15um | 19um | 25um | 30um | |||
| Tensile | ||||||||
| Tensile Strength(MD) | N/mm² | D882 | 118 | 115 | 115 | 100 | 100 | |
| Tensile Strength(TD) | 113 | 110 | 110 | 100 | 100 | |||
| Elongation(MD) | % | 115 | 120 | 120 | 120 | 120 | ||
| Elongation(TD) | 110 | 115 | 115 | 115 | 115 | |||
| Tear | ||||||||
| MD | g | D1922 | 11 | 14 | 17 | 24 | 26 | |
| TD | 10 | 13 | 16 | 23 | 24 | |||
| Seal Strength | ||||||||
| MD/Hot Wire Seal | N/mm² | F88 | 0.65 | 0.85 | 1.05 | 1.25 | 1.35 | |
| TD/Hot Wire Seal | 0.65 | 0.85 | 1.05 | 1.25 | 1.35 | |||
| COF(Film to film) | ||||||||
| Dynamic | D1894 | 0.26 | 0.25 | 0.24 | 0.22 | 0.22 | ||
| Static | 0.27 | 0.26 | 0.25 | 0.23 | 0.23 | |||
| Optics | ||||||||
| Haze | D1003 | 2.2 | 2.5 | 2.7 | 2.9 | 3.1 | ||
| Clarity | D1746 | 98 | 97 | 96 | 95 | 94 | ||
| Gloss@45Deg | D2457 | 86 | 85 | 84 | 82 | 80 | ||
| Shrinkage Properties | MD/TD | MD/TD | MD/TD | MD/TD | MD/TD | |||
| Free Shrinkage | 120ºC | D2732 | 55/58 | 54/57 | 53/68 | 50/56 | 50/55 | |
| 125ºC | 56/60 | 56/60 | 56/60 | 53/58 | 53/57 | |||
| 130ºC | 67/68 | 66/68 | 65/67 | 65/65 | 65/65 | |||
